Product Introduction
Our Compressor Nebulizer delivers reliable, high-performance respiratory therapy in a compact, space-saving design — same power, half the footprint. Featuring an oil-free high-efficiency piston pump, it provides consistent atomization with fine mist particles (MMAD < 5 μm) for effective medication delivery to the lower respiratory tract. The compact size makes it ideal for home use with limited storage space.
The Compressor Nebulizer is indicated for the treatment of respiratory conditions including asthma, bronchitis, COPD, and other upper and lower respiratory tract infections. The oil-free high-efficiency piston pump delivers consistent performance with a fine particle size (MMAD < 5 μm) to ensure effective medication deposition in the airways. The compact, space-saving design (185 × 169 × 107 mm) delivers the same power as larger units but with a significantly smaller footprint — ideal for home use and travel. Low-noise operation (≤50 dB) ensures patient comfort during treatment. Manufactured in ISO 13485-certified facilities with CE MDR and FDA clearances.
Specifications
| Product Specification | |
| Model No. | CNB69020 |
| Power | AC 220V 50Hz, 120V 60Hz, 220V 50/60Hz |
| Power Consumption | 168 VA |
| Medication Capacity | 8 mL – 10 mL |
| Operating Vibration Frequency | 110 kHz ± 10 kHz |
| Maximum nebulization rate | ≤0.25mL/min |
| Working Noise Level | ≤ 65 dB(A) |
| Operating Temperature Range | 5°C ~ 40°C |
| Operating Humidity Range | 15%-80% RH |
| Cup Capacity | 10 mL |
Applications
Product Advantages
Compact design — same power, half the footprint (185×169×107 mm).
Fine particle size (MMAD < 5 μm) for effective deposition.
Low-noise operation (≤65 dB) for patient comfort.
Ideal for home use with limited storage space.
Lightweight and portable.
Use Method
Place the nebulizer on a flat, stable surface. Connect the air tube to the nebulizer outlet.
Open the nebulizer cup and add the prescribed medication (8–10 mL maximum).
Close the nebulizer cup securely and attach the mouthpiece or mask.
Plug the device into a suitable power outlet.
Press the power switch. The nebulizer will begin producing mist.
Sit comfortably and breathe normally until the medication is fully nebulized (typically 5-15 minutes).
Turn off the device when mist production stops. Clean all components according to the cleaning instructions.
Packaging Specifications
| Product Carton Specification | |
| Product Weight | 1.3 kg |
| Product Size | 185×169×107 mm |
| Carton Dimensions (L×W×H, cm) | 50×24.5×44 |
| Carton Gross Weight (kg) | 11.82 |
| Pack Qty | 8 pcs/ctn |
